LC-7056 Contact-cold test device赌钱赚钱app

Use: To measure the degree of cold contact (contact resistance-the ability of the glove to prevent heat transfer) test. Standard: EN 511, ISO 5085-1, GB / T 30384;

characteristic:

1. The system includes: contact cold disk device, environmental test box, calibrated hot flow disk, acquisition device and test software;

2. The size and structure of the disk device meet the requirements of ISO 5085-1 Figure 1;

3. T1, T2, T3 temperature measurement, control and standard test software;

4. Heat current disk calibration standard thermal resistance;

5. The environmental test box conforms to ISO 5085-1 Figure 2 and can provide standard test wind speed;

6. The system can automatically perform the "ISO 5085-1 two-plate thermal resistance test". The thermal resistance (R value) of the sample is displayed on the monitoring computer, and a detailed log of the test can be generated in a standard XML format for further analysis in various software;

7. Repeated testing results for the same samples differ by less than 5%, and typical results are within 1% of each other.

Size (length * width * height cm): 75 * 60 * 85

Weight (kg): 200

Installation requirements:

1、 Power supply: AC 220V 50Hz 2000W

2、 Environment: 23 ± 2℃, 50 ± 5% RH

3、 Operation: experimental table

configure:

1. Contact with 1 cold disc unit

2. 1 set of environmental test box

3. Calibrate 1 hot flow disk

4. 1 copy of the collection device and the test software;

5. Computer 1;

6. 1 copy of operation manual (including calibration certificate) in both Chinese and English.
